Length: 555 mm / 22 “
Width: 122 mm / 4,8“
Footspace: 400 mm
Weight: 1 524 g
6061 T6 aluminium
Headtube angle: 83°
Installed with welded front end-caps to prevent cracks
Elite have also now angled the front deck plate to allow for extra nose-blunt room
Straight angled drop-outs making installing pegs much easier
Curved brake mounted with 5mm bolts from the bottom of the deck making installing/tightening the brake super easy!
Elite's V2 decks do fit 125mm wheels. However you may need to adjust the brake.
Wheel Hub Width Compatibility: 24 mm
Wheel Axle Size Compatibility: 8 mm
Dropouts: Regular
Deck | Wheel PU Width Compatibility: 24 mm
Deck | Wheel Diameter Compatibility: 100,110,115,120,125
Deck headtube: Integrated
Deck Neck: Monoblock
Material: Aluminium
Griptape included: No
Brake type: Flex brake
Headtube angle: 83
Headtube height: 100
Footspace: 400
Deck Width: 122
Deck Length: 555
