Weight: 3140 g
Concave: Yes
Deck Width: 114 mm
Deck Length: 530 mm
Deck Neck: Welded
Headset: Integrated
Headtube angle: 82.5 mm
Footspace: 355 mm
Deck material: Aluminium
Heat treatment-Deck: T6
Brake type: Flex brake
Backsweep: Yes
Handlebar Width: 580 mm
Handlebar Height: 620 mm
Handlebar inner diameter: 28,7 mm
Handlebar outer diameter: Oversized 34,9 mm
Handlebar Shape: Y
Slitted: Yes
Handlebar material: Aluminium
Heat treatment-Handlebars: T6
Fork design: Monoblock
Thread: Threadless
Fork Offset: Offset
Fork material: Aluminium
Wheel diameter: 110 mm
Wheel core design: Spoked
Wheel core material: Aluminium
Wheel hub width: 24 mm
PU width: 24 mm
Deck | Wheel Diameter Compatibility: 100,110 mm
Fork | Wheel Diameter Compatibility: 100,110 mm
Axle diameter: 8 mm
Deck | Wheel PU Width Compatibility: 24 mm
Fork | Wheel PU Width Compatibility: 24 mm
Bearing precision: ABEC9
Compression system: ICS-10
Max rider weight: 100 kg
Total height: 860 mm
SCS / Clamp - Number of bolts: 2 mm
