Weight: 4.270 g
Concave: Yes
Deck Width: 127
Deck Length: 520
Deck Neck: Welded
Headset: Integrated
Headtube angle: 83.5
Headtube height: 113
Footspace: 360
Deck material: Aluminium
Heat treatment-Deck: T6
Brake type: Flex brake
Backsweep: No
Handlebar Width: 560
Handlebar Height: 630
Handlebar inner diameter: 28,7 mm
Handlebar outer diameter: Standard 31,8 mm
Handlebar Shape: T
Slitted: No
Handlebar material: CrMo
Primary color: Red
Fork design: Monoblock
Secondary color: Black
Thread: Threadless
Fork Offset: Offset
Fork material: Aluminium
Wheel diameter: 120
Wheel core design: Hollow
Wheel core material: Aluminium
Wheel hub width: 24 mm
PU width: 24 mm
PU hardness: 88A
Deck | Wheel Diameter Compatibility: 100,110,115,120
Fork | Wheel Diameter Compatibility: 100,110,115,120
Axle diameter: 8 mm
Deck | Wheel PU Width Compatibility: 24 mm
Fork | Wheel PU Width Compatibility: 24 mm
Bearing precision: ABEC9
Compression system: SCS
Max rider weight: 100
Total height: 890
SCS / Clamp - Number of bolts: 4
Skill: Advanced
