Concave: Yes
Deck Width: 115
Deck Length: 497
Deck Neck: Welded
Headset : Integrated
Headtube angle: 82.5
Headtube height: 110
Footspace: 350
Deck material: Aluminium
Heat treatment-Deck: T6
Brake type: Flex brake
Backsweep: No
Handlebar Width: 555
Handlebar Height: 620
Handlebar inner diameter: 28,7 mm
Handlebar outer diameter: Oversized 34,9 mm
Handlebar Shape: Y
Slitted: Yes
Handlebar material: Aluminium
Fork design: Monoblock
Thread: Threadless
Fork Offset: Offset
Fork material: Aluminium
Wheel diameter: 110
Wheel core design: Spoked
Wheel core material: Aluminium
Wheel hub width: 24 mm
PU width: 24 mm
PU hardness: 88A
Deck | Wheel Diameter Compatibility: 100,110,115,120
Fork | Wheel Diameter Compatibility: 100,110,115,120
Axle diameter: 8 mm
Deck | Wheel PU Width Compatibility: 24 mm
Fork | Wheel PU Width Compatibility: 24 mm
Bearing precision: ABEC9
Compression system: IHC
Max rider weight: 100
Total height: 870
SCS / Clamp - Number of bolts: 2
Skill: Advanced
